StarTech.com Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
StarTech.com Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
Regular price
$174.99
Sale price
$174.99
Regular price
$0.00
Shipping calculated at checkout.
Description
Description
Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot. The ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card lets you add two gigabit Ethernet ports to a client, server or workstation through a single PCIe slot. Each port provides 10/100/1000 Mbps capable Ethernet and is fully compatible with IEEE 802.3/u/ab standards. Suitable for any standard PCI Express-enabled system, the 2-port Ethernet card supports full-duplex flow control for maximum data transfer speeds of up to 2000 Mbps - an ideal 2-port NIC for setting up dual-homed, or multi-homed host configurations providing added security to corporate networks. The dual-port server adapter is compliant with the PCIe 2.0 standard and features support for Jumbo Frames and 802.1q VLAN tagging as well as Wake on LAN (WoL). The adapter includes an optional low-profile / half-height bracket that can be used for installation into a standard or small form-factor computer chassis. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer
Specification
Specification
General Information
Manufacturer:StarTech.com
Manufacturer Part Number:ST1000SPEXD4
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
Marketing Information:Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot. The ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card lets you add two gigabit Ethernet ports to a client, server or workstation through a single PCIe slot. Each port provides 10/100/1000 Mbps capable Ethernet and is fully compatible with IEEE 802.3/u/ab standards.
Suitable for any standard PCI Express-enabled system, the 2-port Ethernet card supports full-duplex flow control for maximum data transfer speeds of up to 2000 Mbps - an ideal 2-port NIC for setting up dual-homed, or multi-homed host configurations providing added security to corporate networks.
The dual-port server adapter is compliant with the PCIe 2.0 standard and features support for Jumbo Frames and 802.1q VLAN tagging as well as Wake on LAN (WoL). The adapter includes an optional low-profile / half-height bracket that can be used for installation into a standard or small form-factor computer chassis.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Manufacturer:StarTech.com
Manufacturer Part Number:ST1000SPEXD4
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
Marketing Information:Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot. The ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card lets you add two gigabit Ethernet ports to a client, server or workstation through a single PCIe slot. Each port provides 10/100/1000 Mbps capable Ethernet and is fully compatible with IEEE 802.3/u/ab standards.
Suitable for any standard PCI Express-enabled system, the 2-port Ethernet card supports full-duplex flow control for maximum data transfer speeds of up to 2000 Mbps - an ideal 2-port NIC for setting up dual-homed, or multi-homed host configurations providing added security to corporate networks.
The dual-port server adapter is compliant with the PCIe 2.0 standard and features support for Jumbo Frames and 802.1q VLAN tagging as well as Wake on LAN (WoL). The adapter includes an optional low-profile / half-height bracket that can be used for installation into a standard or small form-factor computer chassis.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
Packaged Quantity:1 Each
Product Type:Gigabit Ethernet Card
Interfaces/Ports
Host Interface:PCI Express x1
Total Number of Ports:2
Number of Network (RJ-45) Ports:2
Host Interface:PCI Express x1
Total Number of Ports:2
Number of Network (RJ-45) Ports:2
Media & Performance
Media Type Supported:Twisted Pair
Maximum Data Transfer Rate:1.95 Gbit/s
Media Type Supported:Twisted Pair
Maximum Data Transfer Rate:1.95 Gbit/s
Network & Communication
Network Technology:10/100/1000Base-T
Network Technology:10/100/1000Base-T
Physical Characteristics
Form Factor:Plug-in Card
Height:4.7"
Width:0.7"
Depth:3.6"
Weight (Approximate):1.90 oz
Form Factor:Plug-in Card
Height:4.7"
Width:0.7"
Depth:3.6"
Weight (Approximate):1.90 oz
Miscellaneous
Package Contents:
Device Supported:Server
System Requirements:
Environmentally Friendly:Yes
Environmental Certification:EU RoHS
Environmental Compliance:
Country of Origin:China
End of Life Manual Availability:Yes
EU RoHS Declaration URL:https://media.startech.com/cms/pdfs/st1000spexd4_rohs.pdf
REACH Declaration URL:https://media.startech.com/cms/pdfs/st1000spexd4_rohs.pdf
REACH free of SVHC:Yes
WEEE Statement:https://media.startech.com/cms/pdfs/st1000spexd4_weee.pdf
Package Contents:
- Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
- 1 x Low Profile Bracket
- 1 x Driver CD
- 1 x Instruction Manual
Device Supported:Server
System Requirements:
- Windows® 2000, XP, Vista, 7, 8, 8.1, 10
- Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
- Mac OS 10.4 to 10.9
- Linux 2.4.x to 4.11.x LTS Versions only
Environmentally Friendly:Yes
Environmental Certification:EU RoHS
Environmental Compliance:
- Restriction of Hazardous Substances (RoHS) 2
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:China
End of Life Manual Availability:Yes
EU RoHS Declaration URL:https://media.startech.com/cms/pdfs/st1000spexd4_rohs.pdf
REACH Declaration URL:https://media.startech.com/cms/pdfs/st1000spexd4_rohs.pdf
REACH free of SVHC:Yes
WEEE Statement:https://media.startech.com/cms/pdfs/st1000spexd4_weee.pdf
Warranty
Limited Warranty:2 Year
Limited Warranty:2 Year
