DC Power Supply, 1 – 32 V, 0 – 20 A
DC Power Supply, 1 – 32 V, 0 – 20 A
Regular price
$1,032.00
Sale price
$1,032.00
Regular price
$0.00
Shipping calculated at checkout.
Description
Description
Product Information: ..
High-quality switched-mode power supply in space-saving housing with intelligent control of fan speed to ensure safe and quiet operation. Simple, precise and fast adjustment of voltage and current levels with dual-function rotary knobs for coarse and fine adjustment. Adjustable current limiting in open circuit. Three user-definable stored configurations for voltage and current limiting make it easy to recall frequently used settings. Full remote control of voltage and current plus output which can be turned on and off.
Sorry, not available in 115 V.
Specifications: ..
Output voltage: 1 – 32 V DC
Output current:. 0 – 5 A (output with 4-mm safety sockets on front);
0 – 20 A (output with pole terminals on rear)
Max. power output: 640 VA
Residual ripple: 5 mV rms
Efficiency: > 87.0 %
Display: three-digit, 15 mm, green LED
Dimensions: 200 mm x 90 mm x 255 mm approx.
Weight: 2.6 kg approx
Specification
Specification
| Weight | 7.72 lb |
| Product Area | Physics |
