APC by Schneider Electric 5000VA Step-Down Rack-mountable Transformer
APC by Schneider Electric 5000VA Step-Down Rack-mountable Transformer
Regular price
$1,294.99
Sale price
$1,294.99
Regular price
$0.00
Shipping calculated at checkout.
Overview
Overview
Description
Description
The APC step-down transformers are used to convert a higher input voltage (208V-200V) to a lower output voltage (120V-100V) which might be more fitting for certain environments or system configurations.
Specification
Specification
General Information
Manufacturer:Schneider Electric SA
Manufacturer Part Number:AP9628
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Name:5000VA Step-Down Rack-mountable Transformer
Marketing Information:
Packaged Quantity:1 Each
Product Type:Step Down Transformer
Manufacturer:Schneider Electric SA
Manufacturer Part Number:AP9628
Manufacturer Website Address:http://www.schneider-electric.com
Brand Name:APC by Schneider Electric
Product Name:5000VA Step-Down Rack-mountable Transformer
Marketing Information:
The APC step-down transformers are used to convert a higher input voltage (208V-200V) to a lower output voltage (120V-100V) which might be more fitting for certain environments or system configurations.
Packaged Quantity:1 Each
Product Type:Step Down Transformer
Technical Information
Power Rating:5000 VA
Input Receptacle Type:Hard Wire 3-wire (2PH + G)
Output Receptacle Type:Hard Wire 3-wire (H+N+E)
Output Receptacle Detail:1 x Hard Wire 3-wire (H+N+E)
Power Rating:5000 VA
Input Receptacle Type:Hard Wire 3-wire (2PH + G)
Output Receptacle Type:Hard Wire 3-wire (H+N+E)
Output Receptacle Detail:1 x Hard Wire 3-wire (H+N+E)
Power Description
Input Voltage:208 V
Output Voltage:120 V AC
Maximum Line Current:26 A
Input Voltage:208 V
Output Voltage:120 V AC
Maximum Line Current:26 A
Physical Characteristics
Color Family:Black
Product Color:Black
Form Factor:Rack-mountable
Mounting Location:Front
Mounting Preference:No Preference
Rack Height:2U
Height:3.5"
Width:17.5"
Depth:24"
Weight (Approximate):95.20 lb
Color Family:Black
Product Color:Black
Form Factor:Rack-mountable
Mounting Location:Front
Mounting Preference:No Preference
Rack Height:2U
Height:3.5"
Width:17.5"
Depth:24"
Weight (Approximate):95.20 lb
Miscellaneous
For Country/Region:United States
Package Contents:5000VA Step-Down Rack-mountable Transformer Rack mounting brackets User manual
Certifications & Standards:CSA|UL Listed
Product Take Back Program:Yes
Mercury Free:Yes
RoHS Exemption Information:https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9635_ROHS_DECLARATION&p_FileName=AP9635KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759642&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759642&lang=en-us
Environmental Profile Availability:https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1511005EN
End of Life Manual Availability:https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1511005_EN
REACH free of SVHC:No
Lead Free:Yes
WEEE Statement:The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Country of Origin:Philippines
Environmentally Friendly:Yes
Environmental Compliance:Restriction of Hazardous Substances (RoHS)
For Country/Region:United States
Package Contents:
Certifications & Standards:CSA|UL Listed
Product Take Back Program:Yes
Mercury Free:Yes
RoHS Exemption Information:https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP9635_ROHS_DECLARATION&p_FileName=AP9635KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759642&lang=en-us
EU RoHS Declaration URL:https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759642&lang=en-us
Environmental Profile Availability:https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1511005EN
End of Life Manual Availability:https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1511005_EN
REACH free of SVHC:No
Lead Free:Yes
WEEE Statement:The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Country of Origin:Philippines
Environmentally Friendly:Yes
Environmental Compliance:Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:2 Year
Limited Warranty:2 Year
